Product Code
Clear Opening mm
Over Base mm
Total Depth
BS EN124 CLASS
4040B
340x340mm
400x400mm
50mm
EN124 B125
5050C
435x435mm
500x500mm
50mm
EN124 C250
6060C
550x550mm
600x600mm
60mm
EN124 C250
4949C
390x390mm
490x490mm
50mm
EN124 C250
5959B
480x480mm
590x590mm
50mm
EN124 B125
6060D
480x480mm
600x600mm
75mm
EN124 D400
7070D
580x580mm
700x700mm
75mm
EN124 D400
سمات:
Made from spheroidal graphite ductile cast iron, according to ISO 1083 (Type QT500-7) and Compliant with the European standard UNE EN-124and ISO9001:2015
Maximum aperture angle of 120º.
Hinged Type
Lockable devices
Anti-Skid Checker design
Manufactured as per BS EN 124
Ductile Iron for high strength and low weight
Black Bitumen Coated
Made in China
