Product Code
Clear Opening mm
Over Base mm
Total Depth
BS EN124 CLASS
SR-8560B
Φ600mm
850x850mm
70mm
EN124 B125
SR-8560C
Φ600mm
850x850mm
80mm
EN124 C250
SR-8560D
Φ600mm
850x850mm
100mm
EN124 D400
SR-6040B
Φ400mm
600x600mm
50mm
EN124 B125
SR-5037B
Φ370mm
500x500mm
50mm
EN124 B125
ФУНКЦИИ:
Made from spheroidal graphite ductile cast iron, according to ISO 1083 (Type QT500-7) and Compliant with the European standard UNE EN-124and ISO9001:2015
Maximum aperture angle of 120º.
Hinged Type
Lockable devices
Anti-Skid Checker design
Manufactured as per BS EN 124
Ductile Iron for high strength and low weight
Heavy duty Traffic loading
Single Seal
Black Bitumen Coated
Made in China
